Figure 2 (IMAGE)

Advanced Institute for Materials Research (AIMR), Tohoku University

Figure 2

Caption

(a-c) SEM images of electrodeposited PbO₂ electrode. (d) HADDF-STEM image of exfoliated PbO₂ nanosheet. (e-h) Time-resolved in-situ TEM images of electrochemical deposition PbO₂ on a glassy carbon microelectrode at a constant potential of 0.9 V vs. Pt. The electron flux during imaging was maintained at ~0.8 e− Å−2 s−1. Scale bar: 5 μm.
