Figure 2 Performance of two-terminal β-Ga₂O₃ photo-synapses.

Caption

Figure 2 Performance of two-terminal β-Ga₂O₃ photo-synapses. a Schematic graph of two-terminal β-Ga2O3 photo-synapses. b PPF behavior of β-Ga2O3 photo-synapses triggered by a pair of successive optical pulses. c PPF index as a function of ∆t. d Spike rate dependent plasticity of β-Ga2O3 photo-synapses. STP-to-LTP transition induced by e light intensity, f duration time, g frequencies. h Learning-experience behavior of β-Ga2O3 photo-synapse. i Long-term conductance under UV optical potentiations and electronic depressions. j Weight update nonlinearity under the optical potentiation and electrical depression behaviors. k Summary of weight update nonlinearity of various photo-synapses.

Credit

Shujie Jiao et al.

Usage Restrictions

Credit must be given to the creator.

License

CC BY
