High-speed quantitative monitoring of highly-dynamic flow field (IMAGE)
Caption
a, A 8×6×3.5 cm silicone phantom was fabricated with a 6×4×2.5 cm well as container. The well was initially filled with liquid phantom (60 ml 1% intralipid) before monitoring. b, The halftone-SFDI was used to monitor the center of the liquid phantom with a 1×0.7 cm field-of-view. The monitoring was conducted at 1,000 Hz with 470 nm and 625 nm wavelengths. A dynamic flow with absorption and scattering contrasts was induced by injection of a solution made with nigrosin and 20% intralipid. c, The extracted absorption and reduced scattering maps, as well as chromophore maps at three representative time points are demonstrated for the quantitative monitoring of the flow field.
Credit
by Yanyu Zhao, Bowen Song, Ming Wang, Yang Zhao, and Yubo Fan
Usage Restrictions
Credit must be given to the creator.
License
CC BY
